3D Product Design: Visualise with Creo View MCAD

Many organisations rely on a wide range of tools to make digital product design content. Yet, as it is increasingly necessary for many people to be able to access and analyse the data, so it is essential to have access to intuitive, powerful visualisation tools to make this possible.  Creo View MCAD allows you to easily visualise products as part of your 3D product design, while also accessing essential engineering data. Creo View MCAD can be used with data from all major MCAD tools. Additionally, it can be used with design drawings, documentations and imagery from multiple sources. Plus, there is no need to have access to the native authoring application. It is now possible for everyone in an organisation to contribute to the design process, be this in real-time or through using mark-ups.

Also, as Creo View ECAD and Creo View MCAD both leverage the same structure, users are able to execute functions across both, for example cross app probes of ECAD/MCAD abstraction.


Features & benefits of Creo View MCAD

  • Increase efficiency by allowing users to easily share visual data throughout the organisation for 3D product design
  • Visualise heterogeneous MCAD data, images, PCB designs and documents in a single  environment, without native authoring applications
  • Supply improved, model-based definitions, with annotations and details, for your quality, inspection and manufacturing engineers
  • Precisely calculate, section and evaluate 3D models, and amass product parts and compound product structures
  • Collaborate on 3D product design with centrally retained digital product information using both markups and real-time input
